Raspberry Pi GPIO paper template
Print out the paper template and put it onto your Raspberry's GPIO ports: This way you'll always know what each pin does!Download: GPIO Pin templateThis sketch gives an overview of the GPIO pins (General Purpose in / Out) of the Raspberry Pi: While some of the pins supply 3.3V or 5V current, others can be controlled by software: Here the status can be queried with a program or current can be sent on request: for example, a connected LED can set... Read more...
